The Tealware User Manual is available via electronic download.  If desired, this printed version is available for purchase.  Hardcover Binder ~170 pages. Includes detailed specifications, system configuration, installation guidelines, analog/special module programming, driver configuration and more.

About Tealware I/O

Tealware modules mount into a backplane. Configuration options include high speed local I/O or ModbusTCP Ethernet I/O configurations:

  • Up to (3) modules can be mounted directly to a Smart SoftPLC or Smart Adapter equipped with a Backplane-3 interface
  • An I/O Base (IOBASE08) can hold any mix of up to (8) modules plus a Tealware Power Supply Module (PWS11 or PWS20C), and connect via an Expansion I/O Cable to a Smart SoftPLC or Smart Adapter equipped with a Local Ports interface

Common features to all Tealware modules make your control system robust, and simplify installation and maintenance:

  • Detachable front-end terminal block/cable for easy module replacement without re-wiring
  • Front Panel LED display for status monitoring/troubleshooting
  • High noise immunity
  • Automatic Configuration – Module addressing based on location (not DIP switch) for easy system configuration & maintenance (manual configuration option also available)
SKU: TW-MN

Options:  Your selections are appended to the part number (SKU), separated by dashes in the order listed below (if applicable).

Weight: 2 lbs
Dimensions: 9.5 × 15.5 × 0.5 in

TW-MN: Tealware Manual

Hard Copy Tealware I/O Users Guide

Product Specifications More info…

$250.00
